HARDWARE FEATURES
Interface USB 3.0
Button WPS button
Dimensions (W X D X H) 3.6×1.2×0.6 in. (92.2×29×14.6mm)
Antenna Type Omni Directional
WIRELESS FEATURES
Wireless Standards IEEE 802.11ac, IEEE 802.11a,
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Frequency 5GHz
2.4GHz
Signal Rate 5GHz
11ac: Up to 867Mbps(dynamic)
11a: Up to 54Mbps(dynamic)
2.4GHz
11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Reception Sensitivity 5GHz:
11a 6Mbps: -88dBm
11a 54Mbps: -71dBm
11ac HT20: -65dBm
11ac HT40: -60dBm
11ac HT80: -56dBm
2.4GHz:
11b 11Mbps: -90dBm
11g 54Mbps: -73dBm
11n HT20: -71dBm
11n HT40: -68dBm
Transmit Power <20dBm (EIRP)
Wireless Modes Ad-Hoc / Infrastructure mode
Wireless Security Support 64/128 bit WEP, WPA-PSK/WPA2-PSK, 802.1x
Modulation Technology DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM,
256-QAM
OTHERS
Certification CE, FCC, RoHS
Package Contents Wireless Adapter Archer T4U
Resource CD
Quick Installation Guide
USB Extension Cable
System Requirements Windows 8 (32/64bits), Windows 7 (32/64bits), Windows XP(32/64bits)
Environment Operating Temperature: 0?~40? (32?~104?)
Storage Temperature: -40?~70? (-40?~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Interface USB 3.0
Button WPS button
Dimensions (W X D X H) 3.6×1.2×0.6 in. (92.2×29×14.6mm)
Antenna Type Omni Directional
WIRELESS FEATURES
Wireless Standards IEEE 802.11ac, IEEE 802.11a,
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Frequency 5GHz
2.4GHz
Signal Rate 5GHz
11ac: Up to 867Mbps(dynamic)
11a: Up to 54Mbps(dynamic)
2.4GHz
11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Reception Sensitivity 5GHz:
11a 6Mbps: -88dBm
11a 54Mbps: -71dBm
11ac HT20: -65dBm
11ac HT40: -60dBm
11ac HT80: -56dBm
2.4GHz:
11b 11Mbps: -90dBm
11g 54Mbps: -73dBm
11n HT20: -71dBm
11n HT40: -68dBm
Transmit Power <20dBm (EIRP)
Wireless Modes Ad-Hoc / Infrastructure mode
Wireless Security Support 64/128 bit WEP, WPA-PSK/WPA2-PSK, 802.1x
Modulation Technology DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM,
256-QAM
OTHERS
Certification CE, FCC, RoHS
Package Contents Wireless Adapter Archer T4U
Resource CD
Quick Installation Guide
USB Extension Cable
System Requirements Windows 8 (32/64bits), Windows 7 (32/64bits), Windows XP(32/64bits)
Environment Operating Temperature: 0?~40? (32?~104?)
Storage Temperature: -40?~70? (-40?~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
